Shenzhen LCS Display Technology Company., Ltd.
7 Years
| Ask Lasest Price | |
| Brand Name : | SMART LED |
| Model Number : | P3.125 Windows LED Display |
| Certification : | CE,ROSH,FCC |
| Payment Terms : | T/T |
| Supply Ability : | no requirement |
| Delivery Time : | 12 Days |
Windows LED Display Standalone SMD 2020 P3.125 LED Poster Screen For Advertising Shenzhen Factory
P3.125 Windows LED Display Standalone LED Advertising Screen
LED Poster Display Advertisement Board LED Video screen P2.5 Size:1920mm*640mm Advertisement Board
Applications
Product Features
* Cabinet Install to the wall,Module magnet service
* Used LED Processor can open 2 windows on the LED Display.
* Power supply and Controller service from the front side.
What we can do
* Project advise,Make the easy project design,easy for install and service
* Free on-line support
* We will send the setting file send with the goods. And also we will keep the Project file.
DISPLAY SPECIFICATION
Product: P3.125 LED Display Poster
Model.PN NO: 1050mm*1550mm
REV NO:V3.0
Description:
■ Module size: 250mm*250mm SMD Indoor module
■ Cabinet size:1050mm*1550mm
■ Display resolution:320*480
■ Display Brightness:3500mcd
Shenzhen LCS Electronic Co.,Ltd | ||
| Technology department | Quality department | Marketing department |
Product superiority:
| Model | SI-3.125 |
| Pixel Pitch (mm) | 3.125 |
| Pixel Density (dot/m2) | 102,400 |
| LED Type | SMD1921/1415 |
| Module Size (W x H x D)mm | 250x250 x 15 |
| Module Resolution (W x H) | 80x80 |
| Module Weight (Kg) | 0.65 |
| Power Consumption per Module (W) | 45 |
| Driver Mode (Scan) | 1/20 |
| Brightness (cd/m2) | >4,000 |
| Grey Scale (bits) | 14 |
W1000xH1500xT40(75)
Refresh Rate (Hz) >1920
Unit Size (W x H x D)mm
1093 x 1596x40 (75)
Display Size (W x H)mm
1000x1500
Display Resolution (W x H)
320X480
Unit Weight (Kg/pc)
48
<720
| Average Power consumption (W/m2) | 216 |
,a I Degree: H Viewing Angle a | 120. |
| Degree: V | 120. |
| Mini View Distance (m) | 3 |
Max Power Consumption (W/m2)
Operating Use Temperature (°C) | -10°C~40oC/14°F~104oF |
| Storage | -2OC〜53C/-40F〜122 °F |
| Input Voltage | 100-240V |
| Input Power Frequency (Hz) | 50Hz-60Hz |
| Control Type | Network |
| Life Span (hrs) | 60,000 |
| IP Level (Front / Rear) | IP20 / IP20 |
