P3.91 500mmx500mmIndoor SMD 2020 HD LED TV IP33 Show Indoor LED Video Wall Curve lock

P3.91 HD LED Display Indoor Size: 500x500mm

Applications

Product Features

* Cabinet Install to the wall,Module magnet service

* Used LED Processor can open 2 windows on the LED Display.

* Power supply and Controller service from the front side.

What we can do

* Project advise,Make the easy project design,easy for install and service

* Free on-line support

* We will send the setting file send with the goods. And also we will keep the Project file.

PH3.91mm LED SMD Indoor Display Specification and Quotation
Technicial Parameters
LED Parameters
No.	Item	Luminous Intensity		Viewing Angle(H/V)	Wavelength	Test Condition
1	Red LED (Epistar DICE)	800-1000		140º/120º	620-630nm	25℃,20mA
2	Green LED(Epistar DICE)	1300~1500		140º/120º	520-535nm	25℃,20mA
3	Blue LED ( Epistar DICE)	250~500		140º/120º	465-475nm	25℃,20mA
Module Specifications
1	Pixel Pitch	3.91mm
2	Pixel Configuration	3-in-1, SMD 2020
3	Module Resolution	64*64
4	Module Pixles	8192
5	Module Size	250mm X 250mm
8	Hub connection	HUB75E
Cabinet Specification
1	Cabinet Size(WXHXD)	500mmLx500mmHx89mmD
2	Cabinet Resolution	128*128 pixels
3	Module Quanity	4 pcs
4	Cabinet Pixels	16384 dots
5	Pixel Density	65536 dots/m2
6	Average Power Consumption	100W/cabinet
7	Max. Power Consumption	200W/cabinet
8	Material	Alum Die-case
9	Cabinet Weight	8.5 KG
10	Product process	Cabinet Fixed
Screen Parameters
1	Whole LED Display Size
1	Whole Display Resolution
1	Cabinet quantity	10pcs*4pcs =40pcs
2	Brightness	≥800 mcd/㎡
3	Brightness(Max./Min.)	1.2:1
4	Driving Method	1/32 Scan
5	View Angle	Horizontal 140° Vertical 120°
6	Optimal Viewing Distance	5M
7	Brightness Control	Red,Green and Blue 256 Grade/Each
8	Refresh rate	>1920hz
9	Frame Frequency	60Hz
10	Input Voltage	AC220V/50Hz or AC110V/60Hz
11	Defects Rate	≤0.00001
12	Power Consumption	Max.:650W/㎡ Average: 200W/㎡
13	Screen weight	≤25kg/㎡
14	MTBF	>10,000 hours
15	Life span	≥100,000 hours
16	Module Display Brightness Uniformity	<2%
17	Earth Leakage Current	<3mA
18	Protective Grade	IP33
19	Temperature-operating	﹣25℃～45℃
20	Humidity-operating	10%～95%
21	Controlling system	HD System
22	Operating System	WINDOWS
Control system
HD-Player software HD-VP620
				1) Integrated video processing, sending card function, 6 gigabit network port output, total pixels 3.9 million points； 2) 5-channel high-definition digital and analog video input, up to 4K@60Hz input； 3) Multiple audio input and output； 4) Support dual pictures PIP,POP； 5) Free switching of any channel； 6) Parameter setting and saving function, scene preset saving and recall； 7) "Navigation Settings" function, convenient for quick settings； 8) The "connection setting" function no need computer control, and directly sets the connection parameters of each cabinet through the panel buttons; 9) The device can be debugged and controlled through panel buttons, USB, Wi-Fi (mobile APP, developing);
LED processor connection				HD-VP620

Shenzhen LCS Display Technology Company., Ltd. was established in 2010. It is a LED display manufacturer that integrates design, development, production of patches and assembly. In terms of raw materials, we have established a stable cooperative relationship with supporting suppliers. In terms of convenient production, there are 7 high-speed SMT lines and automatic reflow soldering production lines, which can ensure the delivery of orders. For welding quality, we use solder paste welding quality inspection machine to check the stability of welding before each unit board is put on the aging rack. Our company always insist that integrity is the basis, leading production technology is supported, and professional and dedicated services are keys to cooperate with our customers and achieve a win-win situation.

Application areas: dedicated to intelligent transportation, intelligent security monitoring, radio and television broadcasting, video conferencing, intelligent advertising media, real estate and commercial display, science and education stadiums, cultural performance stage display, smart scene creative display, and other smart terminal smart display engineering applications.

Our company is one of the national high-tech enterprises in 2019,

Our company's products have passed: CE certification, 3C certification, green environmental protection certification, strictly improve the product quality management under the ISO9001: quality certification system, and strictly follow the quality inspection procedures and supply of IQC, IPQC, CFQC, QA in the process Chain management.

Our company's products are independently developed, produced, and sold in more than 10 countries domestic and overseas. From 2017 to 2018, we participated in a total of 17 overseas international exhibitions in 8 countries. we have brand honors, qualification certificates, and 109 patents.
