Shenzhen LCS Display Technology Company., Ltd.
7 Years
| Ask Lasest Price | |
| Brand Name : | SMART LED |
| Model Number : | P1.25 |
| Certification : | CE ,FCC,CCC |
| Price : | 100.00 usd |
| Payment Terms : | T/T |
| Supply Ability : | 3000pcs |
| Delivery Time : | 5days |
Exhibition Hall MINI LED Display1.25mm Pixel Pitch SMD Alum Cabinet GOB 600mm*337.5mm FCC Certificated Shenzhen Factory
INDOOR P1.25 SMD 3IN1 TECHNICAL PARAMETERS
Unit Module | Item | Parameter |
| Model Number | LCS-P1.25-64S | |
| Module size | 150mm*337.5mm | |
| Pixel pitch | 1.25mm | |
| Pixels Density | 640000/m2 | |
| Pixel configuration | 1R1G1B | |
| LED Package mode | SMD -1010 | |
| Pixel resolution | 120dots(W)*135dots(H) | |
| Max Power | 30W | |
| Module thickness | 1.8mm | |
| Weight | 0.45KG | |
| Drive type | Constant drive | |
| Scan mode | 1/64scan | |
| Port type | HUB76D | |
| Brightness of white balance | ≥600cd/㎡ | |
| box | 尺寸 Size | 600mm*337.5mm |
LED Cabinet | Dimension | 600mm*337.5mm |
| Monomer Module Number | 4pcs | |
| Power supply | 5V/60A*1 pcs | |
| Pixel per cabinet | 480*270 | |
| Best viewing distance | 2M～10M | |
| Best viewing angle | 140°(W) 140°(H) | |
| Temperature | torage:-35℃～+85℃ | |
| Relative humidity | 10%-75% | |
| Thickness | 63mm |
Power | Working voltage | AC220V±10% |
| Average Power consumption | <500W/㎡ | |
| Max.Power consumption | <1250W/㎡ | |
| Current | <15mA(single LED) | |
Control system | CPU | Pentium4 or above |
| Operation system | WIN98/2000/NT/XP/WIN7 | |
| Control method | Synchronization | |
Main technical parameter | Driving device | Constant drive IC |
| Refresh frequency | >3840HZ | |
| Grey scale/colors | 65536gray level/16.7M colors | |
| MTBF | >9000hours | |
| Power switch | Automatic switch | |
| Display Mode | ≥1024*768 |
